Relay panel service, ladder diagrams, and logic relay programming for control panels that have run on relay logic for years. We work the panel as it is rather than treating its age as a reason to replace it.

Control panel backplate with a row of plug-in relays on DIN rail, a PLC and power supply above, and terminal blocks below, wired in blue

WHAT WE DO

Relay panels fail in predictable places: chattering contacts, burnt coils, and timers that have drifted out of adjustment. Most of it is a repair rather than a rebuild, and we will tell you which one you are looking at before quoting.

Ladder logic relay and ladder diagram relay work includes redrawing a relay logic diagram from scratch where no documentation exists, which is common on panels modified in the field for years, and those drawings stay with the panel. Programmable logic relays such as Siemens LOGO! and Zelio sit between hard-wired relay logic and a full PLC, and Siemens LOGO programming and Zelio relay programming cover changes to panels already running on those platforms. IDEC WinLDR programming covers the same ground on IDEC controls. When a panel has outgrown relay logic, we scope and price a conversion instead of forcing more relays into a crowded enclosure.

BRANDS & PLATFORMS

Siemens LOGO! Schneider Zelio IDEC Allen-Bradley

FREQUENTLY ASKED QUESTIONS

What's the difference between relay logic and a PLC? Relay logic uses hard-wired relays and timers to run a sequence, while a PLC runs the same logic in software. Programmable logic relays such as Siemens LOGO! and Zelio sit between the two, simple in hardware but programmable.
Do you program Siemens LOGO! or Zelio relays? Yes. Siemens LOGO programming and Zelio relay programming cover changes to existing panels, and IDEC WinLDR programming covers IDEC's programmable controls the same way.
Can you draw up a relay logic diagram if one doesn't exist? Yes, and it is one of our most common calls. We trace the panel and produce a relay logic diagram and ladder diagram relay documentation from what is actually wired rather than what the original print claimed, and that documentation stays with the panel.
When does it make sense to convert relay logic to a PLC? When the panel has outgrown the enclosure or the logic has become too complex to troubleshoot by hand. We scope and price the conversion against continued relay repairs. See Machine Retrofit & Control Modernization for how that work runs. View that page →
Do you fix chattering relays and burnt contacts? Yes, and that is most of the day-to-day relay panel work: chattering contacts, burnt coils, and timers that have drifted, usually without touching the rest of the panel.
